DD Audio D5.1500 – 5 Ch Amplifier

$999 ~~$1,699~~

6 easy payment of $

Laybuy lets you spread the cost of your purchase over 6, interest-free, weekly payments. Select Laybuy as your payment method during the checkout process.
If you do not have a Laybuy account you will be able to create one at checkout.

From $/week

Get what you want at a price you can afford. Choose a finance term below to see the weekly repayment amount and apply online during checkout or in-store.

Choose a Finance Term

Write a Review

Quantity:

- +

Add to Wishlist Added to Wishlist

Order in the next to get it by

Description

D SERIES 5 CHANNEL

Overview

The D5.1500 is a multi-channel + monoblock hybrid amplifier. Unlike other 5 channel amplifiers, the 4 channel portion of the D5.1500 provides a stout 125 watts per channel for driving your mids and highs with ease while the 5th channel, monoblock portion, pushes 1500 watts of next-level power to a truly high output substage. All of this power has been expertly engineered to fit in an amazingly compact chassis which makes finding room to install this much power in today’s cramped autos a breeze. This amplifier has been specifically designed to be a perfect all-in-one solution to those looking to upgrade their entire OEM system: Mids, Highs, and Lows.

D5.1500 Features Include:

125 Watts x 4 Ch + 1500 Watts x 1 Ch
Dimensions: 17.7” x 6.8” x 2.1”
Remote Subwoofer Control w/ Clipping and Low Voltage Indicators
MOSFET Power Supply Amplifier
0 Gauge Set Screw Power Terminals
12 Gauge Set Screw Speaker Terminals
Heavy Duty PCB
Variable HP/LP/BP Crossovers
5-way Protection: Speaker Short, Thermal, Overload, Hi/Low Voltage, DC Offset

Specifications

Test Voltage 14.4
Channels 5
Cont Wattage @ 4ohm (Ch 1-4) 125x4 / (CH 5) 680x1
Cont Wattage @ 2ohm (CH 1-4) 180x4 / (CH 5) 1000x1
Cont Wattage @ 1ohm (CH 5) 1500x1
Max Current Draw - Amperage 230
S/N Ratio >80dB
THD <0.2%
Input Voltage Sensitivity 6V ~ 0.2V
Pass-Through Output No
Remote Subwoofer Control Yes
Speaker Wire Gauge Out 12
Dimensions: in 17.7 x 6.8 x 2.1
Dimensions: mm 450 x 175 x 55
