Product Description

Alpine Authorized Online Dealer

For those who like it loud, Alpine salutes you! Their legendary R-Series subwoofers are made to bring powerful bass to just about any vehicle. The R-W12D4 12″ sub features a cone made from Kevlar® treated pulp — the same material used to make bulletproof vests — while its durable Santoprene™ surround allows for huge amounts of excursion. Alpine built this sub for bassheads who want the best of both worlds: accurate response and otherworldly thump


Power Handling
Power Range: 250W – 750 Watts
RMS Power Handling: 750W
Peak Power Handling: 2250W
Mounting Depth: 162mm (6.375”)
Mounting Diameter: 275mm (10.875”)
Displacement: 0.10 cu. Ft.
Added Volume: 0.09 cu. ft. (Reverse Mount, Magnet Out)
Frequency Response: 24Hz – 200Hz

Material: Oversized Hairline-Textured Mica Poly Dustcap w/ Kevlar Reinforced Pulp Paper Cone Body
Design: 2-Piece Parabolic
Material: Injected Molded Santoprene®
Design: High Amplitude Multi-Roll H.A.M.R Surround Design (Patent Pending)
Material: Conex®
Design: 10 Segment High-Roll Progressive Design
Voice Coil
Material: 180°C High Temp Wire on Sprial-Cut Aluminum Bobbin
Design: 4-Layer Dual Voice Coil
Motor Structure
Pole Geometry: FEA Optimized Design w/ Compound Radius Pole Geometry
Configuration: Radial Vented VC Heat Sink and Airflow Management System (Patent #7,634,101)
Material: Cast Aluminum
Design: Perimeter Vented Heat Transfer (Patent Pending), Integrated Shorting Sleeve and Airflow Management System
Layout: One Sided
Design: Heavy Duty 8 gauge Push with Housing, Banana Plug Jumper
